Dynamo

Compact Affordable Performance

Versatile, compact, and affordable, Dynamo is engineered to MartinLogan's highest standard to deliver superior bass performance.

Every element of Dynamo, from driver to amplifier to crossover to cabinet, is meticulously designed and manufactured to our highest standard. The result is staggering low-frequency performance for a subwoofer of its size and price. And its versatility is second to none. Variable phase and low-pass crossover controls enable custom tailoring to any system and environment. Dynamo can also be quickly reconfigured for either down- or front-firing operation.

Launched in 2004

Price when discontinued:
$649.00 each

Press For Dynamo

Dynamo Specifications

Specifications are subject to change without notice

Frequency Response

25–120 Hz ±3dB; Anechoic through LFE effects input

Impedance

Line level RCA: 20,000 Ohms
LFE RCA: 34,000 Ohms Compatible with 4, 6, or 8 Ohm rated amplifiers.

Low Frequency Transducer

10" (25.4cm) high excursion, aluminum element woofer with extended throw drive assembly

Amplifier

200 watts rms

Components

Custom wound audio transformer, polypropylene capacitors, air core coils

Audio Controls

Power: Auto/On/Standby

High Pass Filter Frequency

70 Hz

Low Pass Filter Frequency

30–80 Hz

Inputs

RCA line level; RCA LFE; speaker level

Weight

28.5 lbs. (12.9 kg)

Dimensions (front-firing configuration)

13.9" x 11.7" x 12.9"
(35.3 cm x 29.7cm x 32.8cm)

Dimensions (down-firing configuration)

13.9" x 11.7" x 12.6 "
(35.3cm x 29.7cm x 32cm)

Customer Reviews For Dynamo

Please, Sign in or Sign up to add comments.

One Happy User

  • Wednesday, November 6, 2013

I can't say enough
I have had my Dynamo for 8 years now. It has never given me any troubles but I must admit I respect it's limits and take very good care of my equipment. To describe myself I'm that guy who will return anything if I'm not 100% happy. From the day I brought this home and used it I was wowed. The money was well spent as I felt the quality far surpassed the price of $650. As of today I was lucky enough to find a new out of box Dynamo making this my second sub. They are a small, clean looking powerhouse that pumps out only quality sound. I prefer these over the current models. Nice job ML

Rocky Osborn

  • Monday, March 5, 2012

Service
I just want to thank the folks at Martin Logan. The customer service is second to none. After my 5 year old gave my dog my grill cover off my dynamo(wich is discontinued)as a chew toy. You found me one and at a very reasonable price. Thanks again. You made me feel like you really cared. You have a customer for life.

JoshW

  • Wednesday, September 21, 2011

Fantastic, solid subwoofer
I've had the original Dynamo for some time now. I've had it set up in the corner back next to the couch. I'm honestly not sure which configuration I prefer (still). The front firing mode, seems like I can crank it a little bit more, but the down firing turns the whole living room floor into a shake-plate. I'm proud to brag about my subwoofer, and I'll probably stick with ML from here on out when it comes to my subs.

JoshW

  • Wednesday, September 21, 2011

Fantastic, solid subwoofer
I've had the original Dynamo for some time now. I've had it set up in the corner back next to the couch. I'm honestly not sure which configuration I prefer (still). The front firing mode, seems like I can crank it a little bit more, but the down firing turns the whole living room floor into a shake-plate. I'm proud to brag about my subwoofer, and I'll probably stick with ML from here on out when it comes to my subs.

JoshW

  • Wednesday, September 21, 2011

Fantastic, solid subwoofer
I've had the original Dynamo for some time now. I've had it set up in the corner back next to the couch. I'm honestly not sure which configuration I prefer (still). The front firing mode, seems like I can crank it a little bit more, but the down firing turns the whole living room floor into a shake-plate. I'm proud to brag about my subwoofer, and I'll probably stick with ML from here on out when it comes to my subs.

taxalicious

  • Monday, May 31, 2010

Accurate and Clean bass that pleases the wife!
I could not be happier with the Dynamo. I am a home theater enthusiast without a lot of money (with school, student loans and a large family, my dollars go to higher priorities). I put myself through graduate school selling and installing high-end systems. I sold Martin Logan whenever my customers could afford it and I always dreamed of owning that quality of sound. When I could finally afford to invest a little more money in my system, this Dynamo replaced a Infinity 10" sub. Before, with the Infinity 10", my wife would always make me turn down the sub volume- she said she hated the bass "in her face". She didnt like the booming (and changing the cross-over didnt satify her). Well, it turned out that she just hated the bad bass in her face, because she is just fine with the Martin Logan Dynamo. The bass is so clean that I now get to have the volume level where I like it and she doesnt mind. With its clean sound and low distortion, my home theater now envelopes the room with a sweet and powerful blanket of lower range beauty. Not in your face booming, just great sound in high quantity. IT IS AWESOME!!! Being the geek that I am, I whipped out the decible meter and proved my theories. I can play the Martin Logan at higher decibles without wife complaints.

chacon130

  • Thursday, March 25, 2010

GREAT SUBWOOFER
AT FIRST I DIDN'T KNOW WHAT TO EXPECT FROM THE SIZE OF THIS SUB, BUT AFTER HOOKING IT UP, I WAS BLOWN AWAY. I MATCHED THIS SUB WITH FIVE B & W M1 SURROUND SOUND SPEAKERS. I DON'T CONSIDER MYSELF AN EXPERT, BUT I DO HAVE AN EAR FOR QUALITY SOUND, AND THAT'S EXACTLY WHAT THIS SUB HAS TO OFFER. ACCURATE AND PRECISE BASS THAT SOUNDS GREAT WITH MUSIC AND MOVIES. I SHOULD MENTION THAT I LOOKED AT B & W, KLIPSCH, PARADIGM, MIRAGE, DEFINITIVE TECH AND I WAS SOLD ON THIS PRODUCT THROUGH EXTENSIVE RESEARCH AND READING NUMEROUS FIVE STAR REVIEWS. I RECOMMEND MARTIN LOGAN TO ANYONE LOOKING FOR A WELL MADE PRODUCT AT A REASONABLE PRICE. TRULY A FIVE STAR PRODUCT.

Lucky Fry's

  • Sunday, January 17, 2010

Fantastic Subwoofer!
Unbelievable sound! This subwoofer replaced a forward firing Velodyne 3500 that just didn't fit my needs. Once the Dynamo was installed and tucked away, no one else that listened to it could tell where the sound was coming from. Perfect blend with a pair of in-wall Sonance speakers and new Sharp LED TV. I was very lucky to get the last new in box subwoofer from Fry's - many thanks to the helpful salesperson who scoured the warehouse for a couple of hours! If you're considering a new subwoofer, look no further than the latest Dynamo 700.

Ricardo Arriaga

  • Tuesday, December 15, 2009

Awesome subwoofer
For the las 2 years i been running dual suwoofers, they were the Klipsch RW-10D and the Klipsch sub-12. They were great souding subs till the moment i heard the Dynamo at the Magnolia store, then i realized the klipsch were cheap sounding and so boooomy. Don't get me wrong, i am in love with the sound of the klipsch speakers, actually all my speakers are klipsch reference series but i believe the ML subs are way better. I bought two Dynamos that day, they are smaller, with a suposed lower power than the klipsch ones, but let me tell you one thing this two Dynamos overpower my old ones, the bass is extremly tight, with very fast response, drums, gunshots, cars and helicopter or any bass heavy note are reproduced with an awesome fidelity. I do highly recomend this sub to anyone looking for an extremly accurate subwoofer, if you are especting boominess then look somewhere else because you wont find it on the Ml's.

not happy

  • Tuesday, December 15, 2009

I WISH IT WOULD WORK
I bought it on a friday 12/11/09 going against my best judgemet because I own all mirage but I've heard so much about martin logan and when I asked the salesman he said it was the best. I got it home pluged it in read the instructions on hrz here to place it and nothing..It worked for about 1hr and poped the fuse so I tryed a new one nothing will happen. just poped fuses..I'm not happy at all. I moved my mirage upstairs witch I've had for 11 years with no problems and beleive me when I say I use it.
